D-Link DES-1024D Quick Intallation Guide

4
Power
The Switch can be used with AC power sources 100 - 240 VAC, 50 - 60
Hz. The Switch’s power supply will adjust to the local power source
automatically and may be turned on without having any or all LAN segment
cables connected.
LED Indicators
The LED indicators of the Switch include Power, Link/Act and 100Mbps.
The following shows the LED indicators for the Switch along with an
explanation of each indicator.
The Switch LED indicators
 POWER This indicator lights green when the Switch is receiving power,
otherwise, it is off.
 Link/Act. These LED indicators are lighted up when there is a secure
connection (or link) to any ports. The LED indicators blink whenever
there is reception or transmission (i.e. Activity--Act) of data occurring at a
port.
 100Mbps. These LED indicators are lighted up when there is a secure
connection (or link) to 100Mbps Fast Ethernet device at any of the ports.
This Manual: http://www.manuallib.com/file/2426647

D-Link DES-1024D Specifications

General

MAC address table	8000 entries
Store-and-forward	Yes
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u
Switch type	Unmanaged
Switch layer	L2
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports quantity	24
Safety	UL
Product color	Black
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Dimensions (WxDxH)	280 x 44 x 180 mm
Networking features	Fast Ethernet
Connectivity technology	Wired
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	1900 g
