11D-Link DHP-600AV/DHP-601AV User Manual
Section 2 - Installation
Power
Plug the DHP-600AV into an AC wall outlet.
Note: Power supply is conrmed when the Power LED on the DHP-600AV is illuminated.
Connect the Ethernet Cable
Connect the included Ethernet cable to the network cable connector located on the DHP-600AV and attach the other end of
the Ethernet cable to the network or a PC. A lit Ethernet LED indicates a connection between your PC and the DHP-600AV.
For DHP-600AV:
1
ROOM C
DHP-600AV
PC
2
ROOM A ROOM B ROOM C
DHP-600AVDHP-600AV
RouterInternet
PC
DHP-600AV
PC
EXISTING PLC NETWORK
