D-Link DHP-P306AV - LED Indicators

6D-Link DHP-P306AV User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
Ethernet LED
• Solid. The Ethernet port is linked.
• Blinking. The device is transmitting data.
• O. There is no Ethernet connection.
PowerLine LED
• Solid. The device is connected to a PowerLine network.
• Blinking. The device is transmitting data.
• Off. The device has not found any other compatible
PowerLine devices using the same encryption key.
The color indicates the PowerLine link rate:
• Green. The PowerLine link rate is best.
• Amber.The PowerLine link rate is better.
• Red. The PowerLine link rate is good.
Power LED
• Solid. The device is receiving
electrical power.
• Blinking. The device is setting
itself up after reset or simple
connect button was pressed.
• O. The device is not receiving
electrical power.
