D-Link DI-624 User Manual

89
Frequently Asked Questions (continued)
Step 3 Create a new
firewall rule:
Leave the second box empty. Under Protocol, select UDP. In the port range boxes,
enter 5060 in the first box and leave the second box empty.
Click Always or set a schedule.
Step 4 Click Apply
and then Continue.
Step 5
Repeat steps 3 and
4 enter ichat2 and
open ports 16384-
16403 (UDP).
How do I set up my router to use iChat? -for Macintosh users-
(continued)
Click Enabled.
Enter a name
(ichat1).
Click Allow.
Next to Source,
select WAN
under interface.
In the first box,
enter an *.
Leave the second
box empty.
Next to
Destination,
select LAN under
interface.
Enter the IP
Address of the
computer you are running iChat from.

D-Link DI-624 Specifications

General

Wireless Standard	802.11g
Frequency Band	2.4 GHz
Wireless Data Rates	Up to 54 Mbps
LAN Ports	4 x 10/100 Mbps
WAN Ports	1 x 10/100 Mbps
Security	WEP, WPA, WPA2
Firewall	SPI
VPN Pass-through	IPSec/PPTP
