9
LEDS
LED stands for Light-Emitting Diode. The DI-804HV has the following LEDs
as described below:
LED
LED Activity
Power
A steady light indicates
a connection to a power sourcea power source
M2 LED
Lights up when the device has an Internet
connection
WAN
A solid light indicates connection on the
WAN port. This LED blinks during data
transmission
COM
A solid light indicates a connection to an
external dial-up analog modem
Flashes once per second to indicate an
active system
LOCAL
NETWORK
(Ports 1-4)
A solid light indicates a connection to an
Ethernet-enabled computer on ports 1-4. This
LED blinks during data transmission
M1 LED
