DIR-120 Ethernet Broadband Router
D-Link DIR-120 User Manual 31
L2TP
If your ISP is using L2TP to provide your Internet connection, the ISP
will give you the necessary information to configure the Router.
There are two ways to enable the router to become a L2TP client, one
is through assigning the router an IP address dynamically, which
means that the DHCP protocol will be implemented by the Router to
automatically configure the IP settings. The user may input the IP
settings manually by choosing the Static IP option above the
configuring area.
After configuration of Internet and local network IP settings is
complete, click the Save Settings button to save the configuration
changes made and reboot the Router.
L2TP Internet Connection configuration menu
