D-Link DIR-2640 User Manual

88D-Link DIR-2640 User Manual
Section 3 - Conguration
Management
Time & Schedule - Time
In the Management menu on the bar at the top of the page, click Time & Schedule. The Time page allows you to congure,
update, and maintain the correct time on the internal system clock. From here you can set the time zone and the Network
Time Protocol (NTP) server.
To congure the Schedule settings, click the Schedule link. Refer to Time & Schedule - Schedule on page 89
Click Save at any time to save the changes you have made on this page.
Time Conguration
Time Zone Select your time zone from the drop-down menu.
Time Displays the current date and time of the router.
Automatic Time Conguration
NTP Server Select from the drop-down menu to either use the D-Link
NTP Server to synchronize the time and date for your router,
or choose Manual to set the NTP server's IP address.

D-Link DIR-2640 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	800 Mbit/s
VPN support	QuickVPN
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Antennas quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Product type	Desktop/pole router
Product color	Gray
LED indicators	LAN, Power, WAN, WLAN
Flash memory	128 MB
Internal memory	256 MB
Processor cores	2
Security algorithms	WPA2-PSK
Power source type	DC
Number of products included	1 pc(s)
