39D-Link DIR-619L User Manual
Section 3 - Conguration
System Check
VCT is an advanced feature that integrates a LAN cable
tester on every Ethernet port on the router. Through
the graphical user interface (GUI), VCT can be used
to remotely diagnose and report cable faults such as
opens, shorts, swaps, and impedance mismatch. This
feature signicantly reduces service calls and returns
by allowing users to easily troubleshoot their cable
connections.
The Ping Test is used to send Ping packets to test if
a computer is on the Internet. Enter the IP Address
that you wish to Ping, and click Ping.
Virtual Cable
Tester (VCT) Info:
Ping Test:
This tool is used to verify the physical connectivity on both the LAN and the WAN interfaces. The Ping Test can be used to test
the status of the Internet.
