DIR-822 AC1200 Wave 2 MU-MIMO Wi-Fi EasyMesh Router
User Manual
Configuring via Web-based Interface
To create a new VLAN, click the ADD button ( ).
Figure 117. The page for adding a VLAN.
You can specify the following parameters:
Parameter Description
Name
A name for the VLAN for easier identification.
VLAN ID
An identifier of the VLAN.
QoS
A priority tag for the transmitted traffic.
Create interface
Move the switch to the right to create an interface that can be used
for creating WAN connections. Upon that the VLAN should include
the WAN port.
Move the switch to the left for the VLAN to work in the bridge
mode. This mode is mostly used to connect IPTV set-top boxes.
Page 149 of 235
