DIR-825/AC Wireless AC1200 Dual Band Gigabit Router with
3G/LTE Support and USB Port
User Manual
Configuring via Web-based Interface
Figure 146. The Advanced / Miscellaneous page.
The following elements are available on the page:
Parameter Description
IGMP
Select a version of IGMP from the drop-down list to enable IGMP.
Such a setting allows using the IGMP Proxy function for all WAN
connections for which the Enable IGMP Multicast checkbox is
selected.
To disable IGMP, select the Off value from the drop-down list.
High priority for IPTV
Select the checkbox to assign a higher priority for IPTV traffic.
Deselect the checkbox so that online games traffic could have a
higher priority.
SIP
Select the checkbox to enable SIP. Such a setting allows using the
SIP ALG function. This function allows VoIP traffic to pass through
the NAT-enabled router.
11
RTSP
Select the checkbox to enable RTSP. Such a setting allows managing
media stream: fast forward streaming audio/video, pause and start it.
PPPoE pass through
Select the checkbox to enable the PPPoE pass through function.
PPTP pass through Select the checkbox to enable the PPTP pass through function.
11 On the Net / WAN page, create a WAN connection, on the Advanced / Miscellaneous page, select the SIP
checkbox, connect the phone cable between a LAN port of the router and the IP phone. Specify SIP parameters on
the IP phone and configure it to obtain an IP address automatically (as DHCP client).
Page 192 of 257
