D-Link DPH-120SE - Port for Connecting; Icon Introduction

Softkey
1/2/3/4
Various functions depending on the phone mode.
Description will be shown in LCD.
Keyboard Dial phone numbers
1.4 Port for connecting
Port Port name Description
Power switch Input: 5V AC, 1A
WAN 10/100M Connect it to Network
LAN 10/100M Connect it to PC
Handset Port type: RJ-9 connector
1.5 Icon introduction
Icon Description
Call out
Call in
Call hold
Auto answer
Call mute
Contact
DND(Do not Disturb)
