D-Link DSL-225 User Manual

D-Link DSL-225 11N VDSL2 Router User Manual
Web User Interface Configuration
Page 104
After clicking the RIP button the following page is available.
In this section we can configure the default gateway parameters for this router.
Version: Select the RIP version number here. Options to choose from are 1, 2, and
Both.
Operation: Select the operation mode here. Options to choose from are Active and
Passive.
Enable: Tick this option to enable the RIP configuration on the specified interface.
Click the Apply/Save button to accept the changes made.
