DSL-2750U Quick Installation Guide
CONNECTING TO PC
PC with Ethernet Adapter
1. Make sure that your PC is powered off.
2. Connect an Ethernet cable between any of four Ethernet ports located on
the back panel of the router and the Ethernet port of your PC.
3. To connect via USB modem: connect your USB modem to the USB port
2
located on the back panel of the router.
!
In some cases you will need to reboot the router after connection of the
USB modem.
4. To connect the router to a DSL line: connect a phone cable between the
DSL port of the router and the ADSL OUT port of the splitter. Connect
your phone to the PHONE port of the splitter. Then connect another
phone cable between a phone jack and the ADSL IN port of the splitter.
5. To connect the router to an Ethernet line: run the Initial Configuration
Wizard and select the router's LAN port that will be used as the WAN
port. Then connect the Ethernet cable between the selected Ethernet port
located on the back panel of the router and the Ethernet line.
6. Connect the power cord to the power connector port on the back panel of
the router, then plug the power adapter into an electrical outlet or power
strip.
7. Turn on the router by pressing the ON/OFF button on its back panel.
8. Turn on your PC and wait until your operating system is completely
loaded.
Now you should configure your PC to obtain an IP address automatically (as
DHCP client).
2 It is recommended to use a USB extension cable to connect a USB modem to the
router.
4
