D-Link DSL-2790U Quick Start Guide

5
Step 7 - Check Installation
1. If the power is connected correctly, the POWER LED will light up.
2. If the grey telephone cable and the splitter are connected
correctly, the ADSL LED will ash and after a few seconds turn
solid green.
3. As the modem router is pre-congured, the INTERNET LED will
turn green after a few seconds.
4. If the yellow ethernet cable is connected correctly, the
corresponding ETHERNET (LAN) LED will light up.
5. Once you have conrmed the above, open your web browser
(e.g. Internet Explorer, Google Chrome, Firefox or Safari) and go
to your favourite website.
Congratulations, you are now connected to the Internet.
Step 5 - Connect PC
Connect the supplied yellow
ethernet cable from the modem
router’s yellow LAN port to your
computer’s ethernet port.
Step 6 - Connect Power
Connect the power adaptor to the
router then plug it into an electrical
outlet. Ensure the electrical outlet is ON.
Press the black power button at the
back of the router to turn on the
modem router.

D-Link DSL-2790U Specifications

Ports & interfaces

RJ-11 ADSL port	1
RJ-45 Ethernet ports	4 x 10/100BASE-TX
USB port	1 x USB 2.0

Power

Input voltage	100~240 V (±20%)
Input frequency	50~60 Hz
Output voltage	DC 12 V
Output current	1 A

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Non-operating temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	0% - 90% non-condensing
Non-operating humidity	5% - 95% non-condensing

Weight and Dimensions

Dimensions	68 x 42 x 51 mm (2.68 x 1.65 x 2 inches)
Weight	113.4 grams (4 ounces)
