DSL-500G ADSL Router User’s Guide
Figure 16. EOA Interface – Modify
To Add or Modify AAL5 Parameters define the following:
EOA Interface
This is used (by the Router) to identify the EOA interface.
If you are adding a new EOA interface, choose the EOA set you want to
define from the pull-down menu (Add menu only).
Conf. IP Address:
The IP address assigned to the interface. If the interface will be used as a
simple bridge to your ISP, then you do not need to specify IP information.
If you enable DHCP for this interface, then the Configured IP address will
serve only as a request to the DHCP server. The actual address that is
assigned by the ISP may differ if this address is not available.
Some ISPs use static IP settings that are manually assigned to each
account. If your service provider instructs you to configure a Static IP
Address, type in the global IP Address for this EOA interface.
Net Mask:
If you are assigned a Static IP Address and Net Mask, type in the Net
Mask for this EOA interface.
Use DHCP:
When checked, this setting instructs the device to accept IP information
assigned dynamically by your ISP’s DHCP server. If the interface will be
used for bridging with your ISP, leave this checkbox unselected.
Select Enable or Disable for DHCP service.
Click the Submit button to save the settings in temporary memory. When you are done making changes to the
configuration settings, open the Commit & Reboot menu and click the Commit button to save your changes to
permanent memory.
