DSL-500G ADSL Router User’s Guide
A
Technical Specifications
GENERAL
STANDARDS:
ITU G.992.1 (G.dmt)
ITU G.992.2 (G.lite)
ITU G.994.1 (G.hs)
ANSI T1.413 Issue # 2
DATA TRANSFER RATE:
G.dmt full rate: Downstream up to 8 Mbps
Upstream up to 640 Kbps
G.lite: Downstream up to 1.5 Mbps
Upstream up to 512 Kbps
MEDIA INTERFACE EXCHANGE:
RJ-11 port ADSL telephone line connection
RJ-45 port for 10/100 BASE-T Ethernet connection
Physical and Environmental
DC inputs:
Power Adapter:
120 VAC to 230 VAC 60Hz 24W
9 V AC 1A
Power Consumption:
9 Watts Max.
Operating Temperature:
5° to 40° C ( 41° to 104° F)
Humidity:
5 to 95% (non-condensing)
Dimensions:
142 mm x 105 mm x 30 mm
Weight:
300 gm
EMI:
FCC Class B
Safety:
CSA International Mark
50
