DSL-604+ ADSL Ethernet Router User’s Guide
50
Runtime Routing Table
The Runtime Routing Table provides a summary of dynamic and static routing information for both the LAN
and WAN interface.
Figure 4- 28. Runtime Routing Table
Information listed in the Runtime Routing Table includes the following:
IP Address IP address of network, subnet or device used for route
Subnet Mask Subnet mask used for route
Gateway IP address of gateway device used for route
Protocol Route protocol or type, Direct or Static
Interface Interface of network, subnet or device used for router, LAN or WAN
Metric Number of hops used/allowed for route
Name Name assigned to route
Filter and Firewall Summary
The Filter and Firewall summary window is a convenient way to view that status of filtering setup for the Router.
Figure 4- 29. Filtering & Firewall Summary
Line Condition
Use the Line Condition summary window for troubleshooting problems with the ADSL connection.
