D-Link DSL-G256DG VDSL Router User Manual
Web User Interface Configuration Page 120
In this section we can modify the IGMP Configuration.
Multicast Precedence: Click to enable or disable multicast precedence.
Default Version: Enter the default IGMP version number here.
Query Interval: Enter the query interval value here.
Query Response Interval: Enter the query response interval value here.
Last Member Query Interval: Enter the last member query interval value here.
Robustness Value: Enter the robustness value here.
Maximum Multicast Groups: Enter the maximum multicast group value here.
Maximum Multicast Data Sources: Enter the maximum multicast data sources
value here.
Maximum Multicast Group Members: Enter the maximum multicast group
member value here.
Fast Leave Enable: Tick this option to enable the fast leave feature.
LAN to LAN (Intra LAN) Multicast Enable: Select this option to enable LAN to
LAN (Intra LAN) multicasting.
Membership Join Immediate (IPTV): Tick this option to enable the membership join immediate (IPTV) feature.
In this section we can modify the MLD Configuration.
Default Version: Enter the default MLD version number here.
Query Interval: Enter the query interval value here.
Query Response Interval: Enter the query response interval value here.
Last Member Query Interval: Enter the last member query interval value here.
Robustness Value: Enter the robustness value here.
Maximum Multicast Groups: Enter the maximum multicast group value here.
Maximum Multicast Data Sources: Enter the maximum multicast data source
value here.
Maximum Multicast Group Members: Enter the maximum multicast group
member value here.
Fast Leave Enable: Tick this option to enable the fast leave feature.
LAN to LAN (Intra LAN) Multicast Enable: Select this option to enable LAN to
LAN (Intra LAN) multicasting.
Click the Apply/Save button to accept the changes made.
