D-Link EXO AX COVR-X1870 - Back Panel

5D-Link COVR-X1870 User Manual
Section 1 - Product Overview
Back Panel
4
1 Power Connector Connector for the supplied power adapter.
2 Power Button Press the power button to power the device on or o.
3 Gigabit WAN Port
Using an Ethernet cable, connect your broadband modem to this port.
4
Gigabit LAN Ports
(1- 4)
Connect Ethernet devices such as computers, switches, storage (NAS) devices, and game
consoles.
5 WPS Button
Press to start the WPS process and automatically create an encrypted connection to a WPS
client.
1
2
3 5
