D-Link EXO AX COVR-X1870 - Hardware Overview

4D-Link COVR-X1870 User Manual
Section 1 - Product Overview
Hardware Overview
LED Indicators for Router Mode and Extender Mode
1
1 Status LED
Solid Red The device is booting up.
Blinking Red The device is in Recovery Mode.
Blinking Orange
The device cannot sync to another device. Once set up, a blinking orange
LED indicates there is no connection to the device.
Blinking Orange
(Fast)
The device is upgrading rmware.
Solid White
The device is powered up and running. Once set up, a solid white LED
indicates a strong connection.
Blinking White
The device is connecting to a wireless client using Wi-Fi Protected Setup
(WPS). Once set up, a blinking white LED indicates a weak connection.
O
The device is powered o. If the device is powered on and Status LED is
disabled, the device is working as normal. Refer to the Admin section on
page 86 for more information.
