IPv6 and IPv4 Technology
The xStack DGS-3200 Series provides current IPv4
networks with a simple migration path to IPv6 and protects
your investment for future network upgrades when greater
security and larger addressing becomes necessary. The
IPv6 multicast host, the latest in protocol technology,
enables maximum hardware performance. MLD snooping
enhances efficiency in selective distribution by forwarding
multicast data to receiving ports, rather than flooding all
ports in a VLAN. Features such as an ACL that is based
on IPv6 Traffic Class, as well as QoS also based on IPv6,
provide faster and more efficient service. IPv6 Management
supports Web, Telnet, and SNMP.
Reliance/Performance Enhancement
To enhance network resilience, the xStack DGS-3200
Series provides Spanning Tree protocols 802.1D, 802.1w,
and 802.1s for redundant bridge paths. Link Aggregation
provides aggregated bandwidth between switches or
servers to increase redundancy for higher availability.
Quality of Service (QoS) incorporates multilayer functions
that support eight queues including 802.1p priority and
packet classification based on TOS, DSCP, MAC, IP, VLAN
ID and L4 TCP/UDP ports, enabling smooth Internet voice,
video and streaming media applications. The switches also
provide a Safeguard Engine™ for network protection to
increase network reliability, serviceability, and availability.
Traffic Control
Network administrators can define throughput levels for
each port to allocate its essential bandwidth. Broadcast
Storm Control and flow-based Bandwidth Control can
reduce the level of damage from virus attacks or P2P
applications to the network.
Single IP Management
To simplify and speed up your management tasks, multiple
switches can be configured, monitored and maintained
from any workstation running a web browser through
one unique IP address. This virtual stack is managed
as a single object, having all units maintained by one
IP address. Up to 32 D-Link switches, each supporting
Single IP Management, can be managed under a single
IP address.
Technical Specifications
Model DGS-3200-10 DGS-3200-24
Device Interfaces 8 10/100/1000BASE-T Gigabit Ports,
2 Combo 10/100/1000BASE-T/SFP Ports,
RS-232 DB-9 Console Port
20 10/100/1000BASE-T Gigabit Ports,
4 Combo 10/100/1000BASE-T/SFP Ports,
RS-232 DB-9 Console Port, RJ-45, SD Card Slot
Diagnostic LEDs Per Device: Power, Console; Per 10/100/1000BASE-T Port:
Link/Activity/Speed; Per SFP Slot: Link/Activity/Speed
Per Device: Power, Console, SD Card, RPS;
Per 10/100/1000BASE-T Port: Link/Activity/Speed; Per SFP
Slot: Link/Activity/Speed
MAC Address Table 8K 16K
Switch Capacity 20Gbps 48Gbps
Max. Packet Forwarding Rate 14.88Mpps 35.7Mpps
Switching Method Store and Forward Store and Forward
Packet Buffer 128Kbytes 768Kbytes
Flow Control 802.3x Standard in Full Duplex Mode
Back Pressure in Half Duplex Mode
802.3x Standard in Full Duplex Mode
Back Pressure in Half Duplex Mode
Power AC Input Power: 100-240 VAC, 50-60 Hz AC Input Power: 100-240 VAC, 50-60 Hz
Dimensions (W x D x H) 11.02in x 7.09in x 1.73in (280mm x 180mm x 43mm) 17.3in x 8.3in x 1.7in (440mm x 210mm x 44mm)
Ventilation Fanless Two Smart Fans (Default Low Speed)
xStack
®
DGS-3200 Series (DGS-3200-10 and DGS-3200-24)
