DAB E.sybox Assembly And Dismantling Guide

Unscrew the two screws and wa-
shers highlighted in this picture
30
29
28
16
To easily remove the pressure
vessel’s klammer, after pulling out
the extractor, rotate it by 180°
and reinsert it. Push it well till it
clicks. Then pull it out again, and
you will see it has caught and
removed the klammer
Easily pull out the pressure vessel
