Factory settings
Identifying
code
Description Value
Installation Memo
TK Backlight lighting T 2 min
LA Language ENG
SP Setpoint pressure [bar] 3,0
P1 Setpoint P1 [bar] 2,0
P2 Setpoint P2 [bar] 2,5
P3 Setpoint P3 [bar] 3,5
P4 Setpoint P4 [bar] 4,0
RI
Revs per minute in manual
mode [rpm]
2400
OD Type of plant 1 (Rigid)
RP
Pressure decrease to
restart [bar]
0,3
AD Address conguration 0 (Auto)
PR Remote pressure sensor Disable
MS Measuring system 0 (International)
TB
Blockage time for water
lack [s]
10
T1 Low pr. delay (KIWA) [s] 2
T2 Delay in switching off [s] 10
GP
Proportional gain
coefcient
0,5
GI Integral gain coefcient 1,2
RM Maximum speed [rpm]
3050 for e.sybox
3200 for e.sybox
30/50
NA Active devices N
NC Simultaneous devices NA
IC
Conguration of the
reserve
1 (Auto)
ET Max. switching time [h] 2
AE Anti-blocking function 1(Enable)
AF Antifreeze 1(Enable)
I1 Function I1 0 (Disable)
I2 Function I2 0 (Disable)
I3 Function I3 0 (Disable)
I4 Function I4 0 (Disable)
O1 Function output 1 2
O2 Function output 2 2
PW Change Password 0
AY Anticycling Function AY 0 (Disabled)
Table 21: Factory settings
