ENGLISH
51
No. CABLE CLAMPS FITTED
FEKABOX 200 1
FEKAFOS 280 4
FEKAFOS 280 DOUBLE 6
FEKAFOS 550 DOUBLE 6
Floats:
The floats (two for FEKAFOS 280 l three for FEKAFOS 280-550 DOUBLE) are already installed and with their
height set inside the tank.
Pass the float connecting cables through the fairleads preassembled on the tank (detail 7, fig. 10), tighten the ring
nut and connect the cable to the control panel as indicated in the respective manual, taking care that the terminals
on the panel correspond to the respective float cables.
TWO FLOATS THREE FLOATS
2
1
CONTRO L PANEL
MA
X
MIN
A
B
3 4
GRE
Y
NOT USED
BLAC K
BRO WN
MA
X
MIN
2
3 41
MIN
A
B
MA
X
MED
5
6
CONTRO L PANEL
GRE
Y
NOT USED
GRE
Y
NOT USED
GRE
Y
NOT USED
GRE
Y
NOT USED
BRO WN
BRO WN
BRO WN
BRO WN
BLAC K
BLAC K
BLA C K
BLA C K
BLUE NOT
USED
BLUE NOT
USED
BLUE NOT
USED
BLUE NOT
USED
BLUE NOT
USED
Fig. 10
For Fekafos 280/280D for cables sec ≥ 4G1.5mm2
