3
Important safety InstructIons
product specIfIcatIons
Overall Dimensions
18 3/16”
(462mm)
22 1/16 (560mm)
17 9/16”
(445mm)
21 9/16”
(548mm)
13/16”
(20mm)
23 1/2”
(596mm)
17 5/16”
(440mm)
All tolerances are + 1/16”, - 0” (+1.6mm, -0)
unless otherwise stated.
overall dImensIons technIcal specIfIcatIons
Power Requirements 120V, 60Hz, 20A dedicated
circuit required
Total Connected
Load
1.8kW (15A)
Power Cord Length 60 inches
Unit Weight 110 lbs.
Shipping Weight 139 lbs.
Fresh Water Capacity 5 Liters/1.3 Gallons
(Model CM24T-1 only)
Minimum Regulated
Input Pressure
1.5 Bar (21.8 psi) at regulator
output connection
Maximum Regulated
Input Pressure
3.0 Bar (43.5 psi) at regulator
output connection
Water inlet diameter 1/4 inch (1/4-19 BSPP thread)
(Model CM24P-1 only)
DANGER
IMPORTANT: Do not store or use combustible, flammable, or explosive vapors and liquids (such as gasoline) inside or in the
vicinity of this or any other appliance.
IMPORTANT: Before performing any type of service or installation, make sure that electrical power to the coffee system is turned
off or that power is disconnected.
IMPORTANT: This appliance is equipped with a three-prong
grounding plug for protection against possible electric shock hazards.
It must be plugged into a dedicated, grounded receptacle. Where a
standard two-prong wall receptacle is encountered, it is the personal
responsibility and obligation of the customer to have it replaced with
a dedicated, properly grounded three-prong wall receptacle. Do not
under any circumstances, cut or remove the third (ground) prong
from the power cord. Do not use an adapter plug. Do not use an
extension cord. Do not use a power cord that is frayed or damaged.
The use of a ground fault interrupter (GFI) is not recommended.
Power cord with
three-prong plug
Grounded type
wall receptacle
