E8
Part Names
BOTTOM VIEW
(Rear of Microwave)
1. Oven door with see-through window.
2. Door hinges.
3. Stirrer cover
DO NOT REMOVE.
4. Turntable motor shaft.
5. Oven light.
It will light when oven is operating or door is open.
6. Safety door latches.
The oven will not operate unless the door is securely
closed.
7. One touch DOOR OPEN button.
Push to open door.
8. FAN HI/LO button.
Push for high/low/off.
9. LIGHT button.
Push for on/off.
(Front of Microwave)
13
14
17
18
FRONT VIEW
10. Auto-Touch control panel.
11. Time display: Digital display, 99 minutes 99 seconds.
12. Ventilation openings.
13. Light cover.
15. Removable ceramic turntable.
The turntable will rotate clockwise or counterclock-
wise. Only remove for cleaning.
16. Removable turntable support.
cavity and the turntable on the turntable support.
17. Removable low rack for broiling and meat and poultry
roasting.
18. Removable high rack for two level baking.
3
2
1
4
6
5
6
7
8 9
10
11
12
