3 -3
SPECIFICATIONS
3
B
C
##
D
A
5
F
A
4
#
E
5
E
4
CABIN MODEL
These dimensions are measured with the standard tires installed to the CABIN model tractor.
H11O302A
ITEM
MODEL
in.(mm)
DK35(CH)SE DK45(C)HSEDK40(CH)SE
143.7(3,650)
124.8(3,170)
64.0(1,625)
96.3(2,445)
74.0(1,880)
49.0(1,245)
14.7(375)
48.7~53.0
(1,237 ~ 1,347)
69.3(1,760)
97.4(2,475)
53.7(1,365)
15.9(405)
49.7 ~ 59.6
(1,262~1,515)
53.9 ~ 59.6
(1,370~1,515)
1. Overall length (A1)
2. Overall length (A2)
3. Overall width (B)
4. Overall height (C)
5. Wheel base (D)
6. Tread (E1)
7. Tread (E2)
8. Ground
clearance (F)
142.3(3,615)
121.1(3,075)
61.6(1,565)
95.3(2,420)
69.5(1,767)
49.1(1,248)
14.3(365)
A1:Overall length including weight
A2:Overall length excluding weight
E1:Front wheel tread
E2:Rear wheel tread
