4
-14
DK35(CH)SE/DK40(CH)SE/DK45(C)HSE
TACHOMETER/HOURMETER
INDICATOR
(1) Tachometer
(2) Hourmeter Indicator
(3) Rated Engine Speed
H11O570A
It indicates the engine rpm that can
drive 540 rpm of the PTO speed. For
speedy and effective work, adjust the
work load so that the engine rpm is
close to this mark " ".
The hour meter indicates the total us-
age time of the tractor in 6 digits. The
last digit represents 1/10 hour.
For example, if the hour meter shows
“005205”, the tractor has been used for
520 hours and 30 minutes.
T46O568A
(1) Fuel Gauge
“E” : Empty “F” : Full
FUEL GAUGE
Make sure to use only genuine fuel
as the engine can be damaged if
unqualified fuel is used.
Use fuel for winter season in cold
weather to start the engine easier.
The gauge needle can move on a
hill or curve as fuel slopes in the
tank.
NOTE
The warning light on the instrument
panel comes on if the fuel level is be-
low the specified value.
This indicates the remaining fuel level
after the key switch is turned to the “ON”
position.
F : Fuel is fully filled.
E : Replenish the fuel tank.
If driving is continued with the needle
below the position “E”, air may enter
the fuel supply system. In this case,
“bleed” the system. (For detailed
instructions, refer to “Bleeding fuel sys-
tem” in the chapter “Service”.)
