DRAFT HITCH AND TRAILER
(1) Draw Bar
The draw bar is used to pull an
implement, such as a trailer. This
tractor is equipped with a draw bar.
Make sure to check the max. towing
weight of the trailer and max. vertical
load that can be applied to the draw
bar.
TG2O616A
(1) Safety Chain
H11O682A
H11O104A
Type Drawbar
Approval number To be announced
Maker Daedong or Kioti
Maximum horizontal load/D-Value : N/A
Towable mass (T) :
8 tonnes
Maximum permissible vertical load on the coupling point :
1,500kg
Position of cou
-
pling point
Height above ground
minimum 337 mm
maximum 437 mm
Distance from vertical plane
passing through the axis of
the rear axle
minimum 860 mm
maximum 860 mm
