CHECKING ENGINE OIL LEVEL(E)
(1) Oil Dipstick
(A) Upper Limit (B) Lower Limit
5. Pull out the oil dipstick, clean it,
and then insert it into its original
position. Then, pull it out again and
check if the oil level is within the
specied range.
6. If the oil level is too low, add some
new oil so that the level is within
the allowable range. (Refer to
"Lubricant" in this chapter for uid
specs)
1. Check the engine oil daily.
2. Park the tractor on a level ground
and lower the implement.
3. If the engine was just running,
wait for approx. 5 minutes before
checking the oil level.
(1) Oil Dipstick
(A) Oil Level is Acceptable Within This Range
-
fore checking the oil level.
•
CAUTION
If oil level is low, do not run
engine.
-
Be sure to check the oil level
a f te r i n s t a ll i n g h y d r a u li c
needed.
Check the oil level with the
-
tended and check again with
cylinders retracted. Add the oil
or lower)
•
•
•
•
TG2O705b
TG2O706b
To Next Page
