13
DIRECTIONS
To assemble the gear mechanism ass’y, reverse the disassembly procedure.
NOTES
7 Remove the tub i assy.
q Remove four special bolt of gear mechanism assy by
using a box wrentch.
8 Lay the front of the washer on the floor.
9 Remove four special bolts of gear protect by using a box
wrentch and remove gear protect.
0 Remove the V-belt.
w Pull out the gear mechanism assy.
To Next Page
