PARTS DIAGRAM
Parts List
NO. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
A01 3619044120 SWITCH SAFETY 030A6, #187, CU/T=0.5 1
A02 52G043J001 REACTOR 4.2MH, 3.7A 1 OPTION
A03 3614802301 SENSOR PRESSURE DC 5V, 2PIN, CDN2-D01N 1
A04 3614276901 PANEL B ABS 1 UV_SPRAY
A05 36100E2F11 RADICAL GENERATOR DRG-220VSNCF FILTER(IN) 1 OPTION
A06 3615407120 VALVE INLET AS 110-130/60, C&R, H 1 127/60
3615407131 220-240V/50, 60Hz, 35MA 220/50
A07 3618912200 UNIT CAPACITOR AS 45.6uF,400VAC,CAN TYPE 1 127/60
3618911400 13.5uF,400VAC,CAN TYPE 220/50
A08 3612902400 HINGE DOOR POLYACETAL 1
A09 3618102500 NOZZLE DETERGENT PP 1
A10 3614522640 PLATE T
PP, COLD+HOT+RINSE, UV_BASE
1
A11 3610909900 SCREW TAPPING T1S TRS 5X30 MFZN 2
A12 3611132710 CASE DETERGENT ABS, RINSE, UV_BASE 1
A13 3610907800 CAP SOFTNER PP 1
A14 3614276701 PANEL SIDE L ABS, UV BASE 1 UV_SPRAY
A15 3614276801 PANEL SIDE R ABS, UV BASE 1 UV_SPRAY
A16 3614279000 PANEL F ABS, UV BASE 1 UV_SPRAY
A17 3618971100 LEVELER LEVELER 1
A18 3611628200 DECO. INMOLD PANEL ABS 1
A19 3611628300 DECORATOR PANEL F PET, 0.188 1
A20 PRPSSW3N11 PCB ASSY 260AWSP 1 127/60
PRPSSW3N12 260AWNP 220/50
A21 361A100601 DOOR B ABS, UV BASE 1
A22 3615110110 SPRING DOOR DWF-100M 1
A23 361A101600 DOOR F ABS 1
A24 3612606900 HANDLE DOOR L ABS, UV BASE 1 UV_SPRAY
A25 3612606800 HANDLE DOOR U ABS, UV BASE 1 UV_SPRAY
A26 3611339000 POWER CORD U VCTF 3X0.75 1.9M GY 1
A27 3618918802 UNIT BUBBLE AS
CDK-115C,L=500,PJ,PAD,CUSH4,#1806
1 127/60
3618919402
CDK-230C,L=500,PJ,PAD,CUSH4,#1806
220/50
A28 3618956910 FILTER UNIT 15MH 0.47ßfi 0.22ßfi 1KPF 1
OPTION
A29 3612788880 HARNESS AS 127V, P, NON-RADICAL, BUBBLE 1 127/60
3612788871 220, P, BUBBLE, NON-RADICAL 220/50
33
✔ Caution
:
In this Service Manual, some parts can be changed for improving, their performance without notice in the
parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service
Information Center (http://svc.dwe.co.kr).
