THE REPAIR
1 separate the back cover from
washing machine
4 turn the case filter ass’y and sepa-
rate it from the drain motor
7 assemble the case filter ass’y that
purchased
0 assemble the hose drain I to the
case filter with bond & clamp
2 remove two screws
5 separate the drain hose i from the
case filter ass’y
8 tie up three screws
q assemble the cavitation hose to
the case filter with bond & clamp
3 remove three screws
6 separate the cavitation hose from
the case filter ass’y
9 tie up two screws
w assemble the back cover to the
washing machine
REPLACE THE CASE FILTER ASS’Y
