34
PARTS DIAGRAM
NO. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
B01 3613213560 HOSE DRAIN O 1089 CTE 950MM 1 NON PUMP
3613218800 HOSE DRAIN O AS LD-PE/EVA L=1600 PUMP PUMP
B02 3614514600 PLATE UPPER PP 1
B03 7112501411 SCREW TAPPING T1 TRS 5*14 MFZN 8
B04 3615302230 SUPPORTER TUB BL SPG 1.6T(R-00, 100C UV) 1
B05 3615302330 SUPPORTER TUB BR SPG 1.6T(R-00, 100C UV) 1
B06 3615302430 SUPPORTER TUB FL SPG 1.6T(R-00) 1
B07 3615302530 SUPPORTER TUB FR SPG 1.6T(R-00) 1
B08 3611413600 COVER BACK SPG 0.4T 1
B09 3610808020 CABINET PCM 0.6 1
B10 3617703000 LEG FIX SBS 2
B11 3610312200 BASE U PP 1
B12 3617702010 LEG ADJUST PP 2
B13 3611402711 COVER UNDER PP 1
B14 3611405320 COVER PUMP PP(B360F) 1
3611405301 UL/CSZ(466FWU, HFH-400)
B15 7112501611 SCREW TAPPING T1 TRS 5*16 MFZN 2
B16 3618957380 UNIT DRAIN PUMP 110-127/60, L=1310VSF 1 127/60
3618957290 230-240/50, L=1310VSF 220/50
B17 3611901531 FILTER AS DWF-5590 DPNF E-TYPE 1
C01 3616105400 BALANCER AS 100'S, HIDDEN 1
C02 3611904700 FILTER AS 100'S LINT FILTER AS 2
C03 3612202900 FRAME FALL PP 1
C04 3618815300 TUB SUS 1
C05 3612507210 GUIDE FILTER AS HIDDEN FILTER(SUS 0.6T) 3
C06 3616008600 SPECIAL BOLT SUS 6 FOR GUIDE FILTER
C07 3616003700 SPECIAL SCREW SUS 5.5*16 12 FOR BALANCER AS
C08 3616008700 SPECIAL NUT SUS 6 FOR GUIDE FILTER
C09 3616003700 SPECIAL SCREW SUS 5.5*16 12 FOR TUB U
C10 3618815503 TUB U 13kg, M/B 1
C11 4507D83080 SPECIAL NUT SUS 304 1
C12 3617200200 FLANGE TUB ADC12, 6FOOT 1
C13 3616007000 SPECIAL SCREW SCM 24H, 6.5*24 12
C14 3610911210 CAP PULSATOR PP, NANO SILVER 1
C15 3616003720 SPECIAL SCREW SUS 6*26.5 1
C16 3619705513 PULSATOR AS PP, NANO SILVER 1
D01 3611413900 COVER TUB O PP 1
D02 3618807100 TUB O 1098 1 NON PUMP
D03 3613265900 HOSE BUBBLE ID=4.0, L=1150MM 1
D04 3619803900 SUSPENSION AS(B) 1398,ROD=612, SPRING=96 1
D05 3619803800 SUSPENSION AS(F) 1398,ROD=612, SPRING=104 1
D06 3613208901 HOSE OVERFLOW PELD, L=280MM 1 NON PUMP
D07 3615408400 VALVE DRAIN AS 1098'S, VE TYPE 1 NON PUMP
