PARTS DIAGRAM
NO. PARTS CODE PARTS NAME DESCRIPTION Q'TY REMARK
D08 3613218500 HOSE DRAIN I AS LDPE+EVA, L=219.5 1 NON PUMP
3613212100 HOSE DRAIN I LDPE+EVA, L=184 PUMP
D09 3610387400 BASE SECEN 2.0T 1
D10 3616006900 SPECIAL SCREW SCM 24H, 6.5*18 4
D11 3616007000 SPECIAL SCREW SCM 24H, 6.5*24 14
D12 3612712200 INNER EARTH WIRE GN VSF(30/0.18) 1
3612713150 HARNESS EARTH WIRE VSF YW/GN L1=620 L2=200
D13 3618957610 MOTOR SYNCHRONOUS 100-130V KD-DW11LD L=1150 1 127/60
3619617620
220/50-60,SV-MX7T06D,#1806-L1150-RED 220/50
D14 3617309600 GEAR MECHANISM GM-1300-KS6P0, REPEAT 1
D15 7341801511 BOLT HEX 6B-1 8*15 MFZN 4
D16 3618301300 PROTECTOR GEAR SBHG 1.6T 1
D17 3616590220 BELT V M20.5, AGING 1 60HZ
3616590230 M21, AGING 50HZ
D18 3614800710 SENSOR HALL AS DWF-100MV, 5.4 1 INVERTER
D19 3611502700 CUSHION DOWN POM(8MM) 2
D20 3964821120 MOTOR CONDENSER WM244XA011 120V L=1450 1 127/60
3964510320 WM244BA011, 1450L, #1806 220/50
D21 7650802528 BOLT HEX 6B-1 8*25 PW(3*28) MFZN 4
D22 3618403510 PULLY MOTOR AS ADC-12, DS=12, DP=52.5, 60Hz 1 60Hz
3618431300 ADC-12, DP=60.5, 50Hz 50Hz
