DAEWOO ELECTRONICS DWF-5550 - 1 Specifications; Feature and Technical Explanation; Feature of the Washing Machine; Water Currents to Adjust the Unbalanced Load

PULSATOR SYSTEM
When the new shaped pulsator is rotated C.W or C.C.W at a high speed, it makes the 'heart-shaped' water currents as
shown below.
AUTOMATIC DRAINING TIME ADJUSTMENT
This system adjusts the draining time automatically according to the draining condition.
FUNCTIONAL PRINCIPLE
1) The micom can remember the time from the beginning of drain to reset point when the pressure switch reaches to "OFF"
point.
2) In case of continuous draining, residual drain time is determined by micom.
Draining time as a whole=D + 60
(T sec.)
4
FEATURE OF THE WASHING MACHINE
1) The first air bubble washing system in the world.
2) Quiet washing through the innovational low-noise design.
3) The wash effectiveness in much more enhanced because of the air bubble washing system.
4) The laundry detergent dissolves well in water because of the air bubble washing system.
5) The adoption of the water currents to adjust the unbalanced load.
6) One-touch operation system.
WATER CURRENT TO ADJUST THE UNBALANCED LOAD
It is a function to prevent eccentricity of the clothes after wash by rotating pulsator C.W and C.C.W for 20 seconds. (But, the
SUIT & SILK course have no operation of the water currents to adjust the unbalanced load.)
EFFECT
It reduces vibration and noise effectively while spinning.
WATER FLOW
AUTOMATIC WATER SUPPLY SYSTEM FOR BLANKET WASH
The water level would be lowered because the blanket absorbs water at the beginning of washing. Therefore, after 30
seconds, the operation is interrupted to check the water level, and then the water is supplied again until the selected water
level is reached.
3
2. FEATURE AND TECHNICAL EXPLANATION
WASH I DRAIN SPIN FILL RINSE 1 I DRAIN SPIN FILL RINSE 2 I DRAIN
...
MOTOR
C.W
SIGNAL
C.C.W
TIME (SEC.) 0.3 0.5 0.3 0.5 0.3 0.5
20 SEC. (About 13 Times)
WATER CURRENTS
A Water is pushed up near the tub
wall by rotation on the pulsator.
B Water is pulled down in the middle
of the tub by rotation of the
pulsator
C Water currents is generated by
rotation of the pulsator.
C
Rotate
A A
B
Good draining The washer begins spin process after drainage.
Draining
Bad draining Draining time is prolonged.
condition
No draining Program is stopped and gives the alarm.
Residual drain time.
The time remembered by micom.
Less than 4 minutes Continue draining.
More than 4 minutes Program stops and gives the alarm with the display lamp.
Drain Time Movement of the program
340
285
230
175
