22
3. F Light bulb
2. Remove the Light bulb by turning it counterclockwise.
(Lamp : 15W)
3. Pull Light-bulb Base down forward with snap, if necessary
In assembling, push it upward with snap.
Be careful not to damage the Liner surface.
4-1. F LOUVER A
1. Remove 4 caps on the louver, using small screw driver.
2. Remove screws.
DISASSEMBLY AND ASSEMBLY
