34
7. Remove connector.
8.
Remove screws on the back of panel.
19. Compressor
1. Remove Machine-room Cover screws.
2. Pull the cover up to remove.
3. Remove P-Relay Band by pressing it up toward the Compressor.
4. Remove Relay Assembly from Compressor.
5. Cut out Service Pipe and tiny pipe of Dryer.
6. Remove Compressor Pipes using soldering torch.
7. Remove 4 Compressor Washers.
DISASSEMBLY AND ASSEMBLY
