33
3. Separate louver and insulator.
4. Be careful not to breake insulator
5. Remove sensor.
18. Front Control Panel
1. Place any sheet right of panel to protect surface of it.
2. nsert small screw driver into the gap to lift panel window up.
3. Insert another driver into the gap and move it left loosen 2 hooks.
4. Pull window out smoothly.
5. Remove 2 screws.
6. Lift up panel to remove
DISASSEMBLY AND ASSEMBLY
