40
* Remove light cover screws.
* Pull down smoothly the
bottom of light cover to
remove.
* Remove the screw of
bracket F-Lamp.
* Remove the left housing.
* Hold the end of F-Fan cover
and pull forward slowly.
* Remove the screw cap on
the F-Louver A with a flat
tip driver.
* Pull out smoothly the
bracket F-Lamp AS.
to remove.
* Remove 3 screws of
F-Louver A.
* Hold the end of F-Louver A
and pull forward slowly.
* Remove the housing.
* Remove the screw of
F-Return cover
and pull out cover.
* Hold the end of F-Louver B
and pull forward slowly.
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
(16)
(17
