31
3. P.C.B. LOCATION NO.
NAME SYMBOL PART CODE SPECIFICATION Q'TY REMARK
1 BUZZER BZ1 3515600100 BM-20K 1
2 C ARRAY CA1 CN4XB-102M 5P(4) 102 M 50V 1
3 C CERA C1~3,5~8 CCZF1H104Z 50V HIKF 0.1uF Z 7
4 C ELECTRO EC1 CEXF1C101V 16V RSS 100uF 1
5 C ELECTRO EC2 CEXF1E102V 25V RSS 1000uF 1
6 CONN WAFER CN1 3519150520 YW396-02V 1
7 CONN FILM CN3 4CW215SBD0 HLEM15S-1 1
8 CONN WAFER CN4 3519150510 YW396-05AV 1
9 DIODE SWITCHING D1,D3~D8 DZN4148--- 1N4148 AUTO 52mm 7
10 DIODE RECTIFIER D9,D10 DZN4004A-- 1N4004A AUTO 52mm 2
11 DIODE ZENER ZD1 DZUZ3R3BSB UZ-3.3BSB 1
12 IC MICOM IC1 13GSG6C6R0 TMP87CH47U 1
13 IC REGULATOR VL1 1CPMC7805C MC7805C 1
14 LED DISPLAY DP1 DDDG631H-- ELF-496GWB 1
15 PCB MAIN M308 3514329900 BOARD(80x155) 1
MAIN PCB
16 R ARRAY RA1 RA-86X104J 6P(5) 1/8 100K OHM J 1
17 R CARBON FILM R8 RD-AZ101J- 1/6 100 OHM 5% 1
18 R CARBON FILM R1~R7 RD-AZ331J- 1/6 330 OHM 5% 7
19 R CARBON FILM R9,11,13,20 RD-AZ102J- 1/6 1K OHM 5% 4
20 R CARBON FILM R10,12,18 RD-AZ103J- 1/6 10K OHM 5% 3
21 R CARBON FILM R17 RD-AZ473J- 1/6 47K OHM 5% 1
22 R CARBON FILM R15 RD-AZ105J- 1/6 1M OHM 5% 1
23 R CARBON FILM R19 RD-4Z510J- 1/4 51 OHM 5% SMALL 1
24 RESONATOR CERA CR1 5P4R00MTS- CRT4.00MS 1
25 SW RELAY RY1,RY3 5SC0101121 G5G-1A 1C 1P DC12V 2
26 SW RELAY RY2 5SC0101128 CS11-12SH 1C 1P 1
27 TR Q1~Q5 TZRA106M-- KRA-106M (AUTO) 5
28 TR Q8~Q12 TZRC106M-- KRC-106M (AUTO) 5
29 TR Q6 TZTA1266Y- KTA-1266Y (AUTO) (1015Y) 1
30 TRANS POWER LVT1 5EPV035303 DMR-631FS 1
31 WIRE COPPER J1~3,14,15,SJ4,SJ5 85801052GY 1/0.52 TIN COATING 7.5mm 7
32 WIRE COPPER J4,7,8,12,13,16 85801052GY 1/0.52 TIN COATING 10mm 6
33 WIRE COPPER J9,10 85801052GY 1/0.52 TIN COATING 12.5mm 2
34 PCB SUB M309 3514330000 BOARD(72.6x93.4) 1 SUB PCB
35 CONN WAFER CN101 4CW215RBD0 HLEM15R-1 1
36 SW ROTARY SW101 5S10302005 EC12E24204A8 1
37 SW TACT SW102~SW107 5S50101Z93 KPT-1115AM 6
38 R CARBON FILM R101,R102 RD-AZ102J- 1/6 1K OHM 5% 2
39 R CARBON FILM R105,R106 RD-AZ103J- 1/6 10K OHM 5% 2
40 R CARBON FILM R103,R104 RD-AZ104J- 1/6 100K OHM 5% 2
41 WIRE COPPER SJ102,SJ104 85801052GY 1/0.52 TIN COATING 7.5mm 2
42 WIRE FLAT WF1 WSJ-159007 1.25X15X90XC 1
To Next Page
