11
Door seal - Door seal maintains the microwave energy
within the oven cavity and prevents microwave
leakage.
22
Reflector (Insulator Heater)
33
Heating Element
44
Oven cavity
55
Safety interlock system
66
Metal Rack
77
Coupler - This fits over the shaft in the center of the
ovens cavity floor. This is to remain in the oven for all
cooking.
88
Roller guide - This must always be used for cooking
together with the glass cooking tray.
99
Glass cooking tray - Made of special heat resistant
glass. Food in a proper receptacle is placed on this tray
for cooking.
00
Door viewing screen - Allows viewing of food. The
screen is designed so that light can pass through, but
not the microwave.
qq
Door hook - When the door is closed, it will
automatically shut off. If the door is opened while the
oven is operating, the magnetron will immediately stop
operating.
