INSTALLATION ON UNIT SUPPORT
1. Wall Mount
AM301 System
Hanging plate x1
screw x1
Install the hanging plate on the
wall with screws.
Note: The screws must all be
screwed to the wall and the
hanging board must be parallel.
Align the hole on the back of the
panel with the hanging plate
and install it.
Note: For concealed wire
installation, please remove the
bracket and wire clip.
To Next Page
