Electrical Parts List
225M 225MU 325M 325MU
PART-CODE PART-DESC
MODEL
NO ASS'Y LOCATION PART-NAME
71 PCB FRONT AS R739 R CARBON FILM RD-4Z103J- 1/4 10K OHM J o o o o
72 PCB FRONT AS R740 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o
73 PCB FRONT AS R741 R CARBON FILM RD-4Z103J- 1/4 10K OHM J o o o
74 PCB FRONT AS R742 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o
75 PCB FRONT AS R751~757 R CARBON FILM RD-AZ182J- 1/6 1.8K OHM J o o o o
76 PCB FRONT AS R765 R CARBON FILM RD-4Z103J- 1/4 10K OHM J o o o o
77 PCB FRONT AS R766 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
78 PCB FRONT AS R770 R CARBON FILM RD-AZ122J- 1/6 1.2K OHM J o o
79 PCB FRONT AS R770 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o
80 PCB FRONT AS R771 R CARBON FILM RD-AZ472J- 1/6 4.7K OHM J o o o o
81 PCB FRONT AS R773 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
82 PCB FRONT AS R780 R CARBON FILM RD-AZ101J- 1/6 100 OHM J o o o o
83 PCB FRONT AS R781 R CARBON FILM RD-AZ151J- 1/6 150 OHM J o o o o
84 PCB FRONT AS R782 R CARBON FILM RD-AZ181J- 1/6 180 OHM J o o o o
85 PCB FRONT AS R783 R CARBON FILM RD-4Z271J- 1/4 270 OHM J o o o o
86 PCB FRONT AS R784 R CARBON FILM RD-AZ331J- 1/6 330 OHM J o o o o
87 PCB FRONT AS R785 R CARBON FILM RD-4Z391J- 1/4 390 OHM J o o o o
88 PCB FRONT AS R786 R CARBON FILM RD-4Z471J- 1/4 470 OHM J o o o o
89 PCB FRONT AS R787 R CARBON FILM RD-AZ101J- 1/6 100 OHM J o o o o
90 PCB FRONT AS R788 R CARBON FILM RD-AZ151J- 1/6 150 OHM J o o o o
91 PCB FRONT AS R789 R CARBON FILM RD-AZ181J- 1/6 180 OHM J o o o o
92 PCB FRONT AS R790 R CARBON FILM RD-AZ271J- 1/6 270 OHM J o o o o
93 PCB FRONT AS R791 R CARBON FILM RD-AZ331J- 1/6 330 OHM J o o o o
94 PCB FRONT AS R792 R CARBON FILM RD-AZ101J- 1/6 100 OHM J o o o o
95 PCB FRONT AS R793 R CARBON FILM RD-4Z151J- 1/4 150 OHM J o o o o
96 PCB FRONT AS R794 R CARBON FILM RD-4Z181J- 1/4 180 OHM J o o o o
97 PCB FRONT AS R795 R CARBON FILM RD-AZ271J- 1/6 270 OHM J o o o o
98 PCB FRONT AS R796 R CARBON FILM RD-4Z331J- 1/4 330 OHM J o o o o
99 PCB FRONT AS R797 R CARBON FILM RD-AZ391J- 1/6 390 OHM J o o o o
100 PCB FRONT AS RM701 IC 1PNA4612HB PNA4612M00HB o o o o
101 PCB FRONT AS SW701~708 SW TACT 5S50101001 KPT-1105A 1C-1P o o o o
102 PCB FRONT AS SW710~718 SW TACT 5S50101001 KPT-1105A 1C-1P o o o o
103 PCB FRONT AS SW719~720 SW TACT 5S50101008 KPT-1105V 1C-1P o o o o
104 PCB FRONT AS SW721 SW TACT 5S50101001 KPT-1105A 1C-1P o o o o
105 PCB FRONT AS SW722 SW TACT 5S50101001 KPT-1105A 1C-1P o o o o
106 PCB FRONT AS XC701 X-TAL 5XA32R768- DT-38 32.768KHZ 20PPM o o o o
107 PCB FRONT AS XC702 RESONATOR 5PCSA8MTZ- CSA8MTZ, 8MHZ o o o o
108 PCB FUSE AS 13000 PCB FUSE AS 9CDC054500 AMI-225M o
109 PCB FUSE AS 13000 PCB FUSE AS 9CDC054501 AMI-225MU o
110 PCB FUSE AS 13000 PCB FUSE AS 9CDC054701 AMI-325MU o
111 PCB FUSE AS 13000 PCB FUSE AS 9CDC054700 AMI-325M o
112 PCB FUSE AS B901 PCB FUSE 9CD6580001 75X33X1.6T o o o o
113 PCB FUSE AS CD901 CORD AC 9736900200 KKP419C,KLCE-2F,0.75SQURE o o
114 PCB FUSE AS CD901 CORD AC 9736905900 KP 10W SPT-2(2M) NM ULCSA o o
115 PCB FUSE AS F901 FUSE GLASS TUBE 5FSGB3112L SEMKO TL 0.315A 250V MF51 o
116 PCB FUSE AS F901 FUSE GLASS TUBE 5FSGB6312L SEMKO TL 0.63A 250V MF51 o
117 PCB FUSE AS F901 FUSE GLASS TUBE 5FSGB8012L SEMKO MF51 800MA 250V TL o
118 PCB FUSE AS F901 FUSE GLASS TUBE 5FSGB4012L SEMKO TL 400MA 250V MF51 o
119 PCB FUSE AS FC901~902 CLIP FUSE 9734600700 FC-5N o o o o
120 PCB FUSE AS PT901 TRANS POWER 5TP8057816 EI=57X30 230V 50HZ o
121 PCB FUSE AS PT901 TRANS POWER 5TP1057815 EI-57X30 127V 60HZ o
122 PCB FUSE AS PT901 TRANS POWER 5TP1066818 EI=66X30 120V 60HZ o
123 PCB FUSE AS PT901 TRANS POWER 5TP8066817 EI=66X30 230V 50HZ o
124 PCB FUSE AS TP901~904 PIN WRAPPING 9716404000 MFZN1.1X1.1 PANASERT o o o o
125 PCB MAIN AS 10000 PCB MAIN AS 9CDC054400 AMI-225M o
126 PCB MAIN AS 10000 PCB MAIN AS 9CDC054401 AMI-225MU o
127 PCB MAIN AS 10000 PCB MAIN AS 9CDC054601 AMI-325MU o
128 PCB MAIN AS 10000 PCB MAIN AS 9CDC054600 AMI-325M o
129 PCB MAIN AS AT001 ANTENNA FM 9736806000 2M ANT PIG TAIL o o
130 PCB MAIN AS AT001 ANTENNA FM 9736805700 2M PIG TAIL o o
131 PCB MAIN AS B001 PCB MAIN 9CD6580000 330X197X1.6T o o o o
132 PCB MAIN AS CC001 C CERA CCXB1H102K 50V B 1000PF K (TAPPING) o o o o
133 PCB MAIN AS CC002 C CERA CCXF1H103Z 50V F 0.01MF Z (TAPPING) o o o o
134 PCB MAIN AS CC004 C CERA CCXF1H103Z 50V F 0.01MF Z (TAPPING) o o o o
135 PCB MAIN AS CC006 C CERA CCXF1H103Z 50V F 0.01MF Z (TAPPING) o o o o
136 PCB MAIN AS CC102 C CERA CCXF1H103Z 50V F 0.01MF Z (TAPPING) o o o o
137 PCB MAIN AS CC103 C CERA CCXF1H104Z 50V F 0.1MF Z o o o o
138 PCB MAIN AS CC104 C CERA CXCH1H120J 50V CH 12PF J (TAPPING) o o o
139 PCB MAIN AS CC104 C CERA CXCH1H150J 50V CH 15PF J (TAPPING) o
140 PCB MAIN AS CC105 C CERA CXCH1H820J 50V CH 82PF J (TAPPING) o o o o
