Daewoo AMI-225M - Electrical Parts List; Component Identification and Specifications

Electrical Parts List
225M 225MU 325M 325MU
1 PCB FRONT AS 12000 PCB FRONT AS 9CDC054300 AMI-225M o o
2 PCB FRONT AS 12000 PCB FRONT AS 9CDC054301 AMI-225MU o
3 PCB FRONT AS 12000 PCB FRONT AS 9CDC054302 AMI-325MU o
4 PCB FRONT AS B001 PCB FRONT 9CD6579800 247X139 o o o o
5 PCB FRONT AS CC701~704 C CERA CCXF1H223Z 50V F 0.022MF Z (TAPPING) o o o o
6 PCB FRONT AS CC705~707 C CERA CCXF1H104Z 50V F 0.1MF Z o o o o
7 PCB FRONT AS CC708 C CERA CZCH1E150J CH 25V 15PF J (AXIAL) o o o o
8 PCB FRONT AS CC709 C CERA CZCH1E180J CH 25V 18PF J (AXIAL) o o o o
9 PCB FRONT AS CC710 C CERA CCXF1H223Z 50V F 0.022MF Z (TAPPING) o o o o
10 PCB FRONT AS CC711~712 C CERA CZCH1E330J CH 25V 33PF J AXIAL 52MM o o o o
11 PCB FRONT AS CC713 C CERA CCXF1H104Z 50V F 0.1MF Z o o o o
12 PCB FRONT AS CC714 C CERA CCXF1H103Z 50V F 0.01MF Z (TAPPING) o o o o
13 PCB FRONT AS CE701 C ELECTRO CEXF1H109V 50V RSS 1MF (5X11) TP o o o o
14 PCB FRONT AS CE702 C ELECTRO CEXF1C101V 16V RSS 100MF (6.3X11) TP o o o o
15 PCB FRONT AS CE703 C ELECTRO CEXF0J102V 6.3V RSS 1000MF 10X12.5 o o o o
16 PCB FRONT AS CE704 C ELECTRO CEXF1H100V 50V RSS 10MF (5X11) TP o o o o
17 PCB FRONT AS CE705 C ELECTRO CEXF1C101V 16V RSS 100MF (6.3X11) TP o o o o
18 PCB FRONT AS CE706 C ELECTRO CEXF1H100V 50V RSS 10MF (5X11) TP o o o o
19 PCB FRONT AS CE707 C ELECTRO CEXF1H479V 50V RSS 4.7MF (5X11) TP o o o
20 PCB FRONT AS CN701~702 PIN WAFER 9736407700 52084-1310 13P BOTTOM o o o o
21 PCB FRONT AS CN703 CONN 9728801900 8P 150MM o o o o
22 PCB FRONT AS D701~704 DIODE DZN4148--- 1N4148 AUTO 52MM o o o o
23 PCB FRONT AS IC701 IC EEPROM 124LC04BP- 24LC04BP o o o o
24 PCB FRONT AS IC702 IC 1M38869225 M38869M8A o o o o
25 PCB FRONT AS IC703 IC RESET 1K1A7029AP KIA7029AP o o o
26 PCB FRONT AS IC703 IC 1K1A7029-- KIA7029 o
27 PCB FRONT AS JW712~713 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
28 PCB FRONT AS JW714 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o o o
29 PCB FRONT AS JW715 WIRE JUMPER W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO o o o o
30 PCB FRONT AS JW716 WIRE JUMPER W581GY1505 AWG22 1/0.65 GY 15 AUTO o o o o
31 PCB FRONT AS JW717~721 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
32 PCB FRONT AS JW722 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o
33 PCB FRONT AS JW723~724 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
34 PCB FRONT AS JW725~727 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o o o
35 PCB FRONT AS JW728~734 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
36 PCB FRONT AS JW735~736 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o o o
37 PCB FRONT AS JW737 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
38 PCB FRONT AS JW738 WIRE JUMPER W581GY1505 AWG22 1/0.65 GY 15 AUTO o o o o
39 PCB FRONT AS JW739~740 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o o o
40 PCB FRONT AS JW741~743 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
41 PCB FRONT AS JW744~745 WIRE JUMPER W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO o o o o
42 PCB FRONT AS JW746 WIRE JUMPER W581GY17J5 AWG22 1/0.65 SN 17.5 AUTO o o o o
43 PCB FRONT AS JW747~748 WIRE JUMPER W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO o o o o
44 PCB FRONT AS JW750 WIRE JUMPER W581GY1505 AWG22 1/0.65 GY 15 AUTO o o o o
45 PCB FRONT AS JW751 WIRE JUMPER W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO o o o
46 PCB FRONT AS JW751 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o
47 PCB FRONT AS JW752~756 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
48 PCB FRONT AS JW760 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
49 PCB FRONT AS LD701 LED DISPLAY DLTG9920M- LTG-9920M 70X24M o o o o
50 PCB FRONT AS Q702~718 TR TZTC3198Y- KTC3198Y-(1815Y) (AUTO) o o o o
51 PCB FRONT AS R701~703 R CARBON FILM RD-AZ103J- 1/6 10K OHM J o o o o
52 PCB FRONT AS R704 R CARBON FILM RD-AZ152J- 1/6 1.5K OHM J o o o o
53 PCB FRONT AS R705~706 R CARBON FILM RD-4Z152J- 1/4 1.5K OHM J o o o o
54 PCB FRONT AS R707 R CARBON FILM RD-AZ334J- 1/6 330K OHM J o o o o
55 PCB FRONT AS R708~709 R CARBON FILM RD-AZ104J- 1/6 100K OHM J o o o o
56 PCB FRONT AS R710 R CARBON FILM RD-AZ334J- 1/6 330K OHM J o o o o
57 PCB FRONT AS R711 R CARBON FILM RD-4Z103J- 1/4 10K OHM J o o o o
58 PCB FRONT AS R712 R CARBON FILM RD-4Z473J- 1/4 47K OHM J o o o
59 PCB FRONT AS R712 R CARBON FILM RD-4Z103J- 1/4 10K OHM J o
60 PCB FRONT AS R713~714 R CARBON FILM RD-4Z103J- 1/4 10K OHM J o o o o
61 PCB FRONT AS R715 R CARBON FILM RD-4Z473J- 1/4 47K OHM J o o o
62 PCB FRONT AS R715 R CARBON FILM RD-4Z103J- 1/4 10K OHM J o
63 PCB FRONT AS R716 R CARBON FILM RD-4Z103J- 1/4 10K OHM J o o o o
64 PCB FRONT AS R717 R CARBON FILM RD-4Z100J- 1/4 10 OHM J o o o o
65 PCB FRONT AS R718 R CARBON FILM RD-AZ106J- 1/6 10M OHM J o o o o
66 PCB FRONT AS R719 R CARBON FILM RD-AZ334J- 1/6 330K OHM J o o o o
67 PCB FRONT AS R720~730 R CARBON FILM RD-AZ101J- 1/6 100 OHM J o o o o
68 PCB FRONT AS R731~737 R CARBON FILM RD-4Z479J- 1/4 4.7 OHM J o o o
69 PCB FRONT AS R731~737 R CARBON FILM RD-4Z339J- 1/4 3.3 OHM J o
70 PCB FRONT AS R738 R CARBON FILM RD-AZ681J- 1/6 680 OHM J o o o o
PART-CODE PART-DESC
MODEL
NO ASS'Y LOCATION PART-NAME
