Electrical Parts List
225M 225MU 325M 325MU
PART-CODE PART-DESC
MODEL
NO ASS'Y LOCATION PART-NAME
281 PCB MAIN AS CM603~604 C MYLAR CMXM1H223J 50V 0.022MF J o o o o
282 PCB MAIN AS CM605~608 C MYLAR CMXM1H102J 50V 0.001MF J (TP) o o o o
283 PCB MAIN AS CM609~610 C MYLAR CMXM1H153J 50V 0.015MF J (TP) o o o o
284 PCB MAIN AS CM611 C MYLAR CMXM1H223J 50V 0.022MF J o o o o
285 PCB MAIN AS CM612 C MYLAR CMXM1H332J 50V 3300 PF J o o o o
286 PCB MAIN AS CM613 C MYLAR CMXM1H153J 50V 0.015MF J (TP) o o o o
287 PCB MAIN AS CM614 C MYLAR CMXM1H152J 50V 1500PF J o o o o
288 PCB MAIN AS CM615~616 C MYLAR CMXM1H102J 50V 0.001MF J (TP) o o o o
289 PCB MAIN AS CM801~802 C MYLAR CMXM1H104J 50V 0.1MF J o o o o
290 PCB MAIN AS CM803~804 C MYLAR CMXM1H473J 50V 0.047MF J o o o o
291 PCB MAIN AS CM901~903 C MYLAR CMXM1H104J 50V 0.1MF J o o o o
292 PCB MAIN AS CN501 CONN AS 9738840800 FFC 16P P1.0X250MM R o o o o
293 PCB MAIN AS CN601 CONN AS 9738834900 UL 2468 #26 4P+3P+2P 360 o o o
294 PCB MAIN AS CN602 CONN AS 9728802100 UL2547 #28X3CO 4P o o o
295 PCB MAIN AS CN603 CONN AS 9738835000 UL 2851 #28X2C0 3P 260MM o o o
296 PCB MAIN AS CN701~702 PIN WAFER 9736407700 52084-1310 13P BOTTOM o o o o
297 PCB MAIN AS CW101 CONN WAFER 9CD6258800 2P S2B-XH-A o o o o
298 PCB MAIN AS CW501 CONN WAFER 9738842900 16P FFC PIT1.0 o o o o
299 PCB MAIN AS CW502 CONN WAFER 9CD6259500 2001-WS-6P o o o o
300 PCB MAIN AS CW503 CONN WAFER 9CD6259400 2001-WS-12P o o o o
301 PCB MAIN AS CW601 CONN AS 9738834900 UL 2468 #26 4P+3P+2P 360 o o o
302 PCB MAIN AS CW602 CONN AS 9728802100 UL2547 #28X3CO 4P o o o
303 PCB MAIN AS CW603 CONN AS 9738835000 UL 2851 #28X2C0 3P 260MM o o o
304 PCB MAIN AS CW703 CONN 9728801900 8P 150MM o o o o
305 PCB MAIN AS CW902 CONN AS 9728802000 VH-02A 3.96 PITCH 2P o
306 PCB MAIN AS CW903 CONN AS 9728802400 VH-05A 3.96 PITCH 5P o o
307 PCB MAIN AS D201 DIODE DZN4148--- 1N4148 AUTO 52MM o o o o
308 PCB MAIN AS D401~402 DIODE DZN4148--- 1N4148 AUTO 52MM o o o o
309 PCB MAIN AS D501 DIODE DZN4148--- 1N4148 AUTO 52MM o o o o
310 PCB MAIN AS D502 DIODE DZN4148--- 1N4148 AUTO 52MM o o o
311 PCB MAIN AS D601 WIRE JUMPER W581GY7595 AWG22 1/0.65 SN 7.5 AUTO o
312 PCB MAIN AS D602~603 DIODE DZN4148--- 1N4148 AUTO 52MM o o o o
313 PCB MAIN AS D605~608 DIODE DZN4148--- 1N4148 AUTO 52MM o o o o
314 PCB MAIN AS D610~611 DIODE DZN4148--- 1N4148 AUTO 52MM o o o o
315 PCB MAIN AS D801~802 DIODE DZN4148--- 1N4148 AUTO 52MM o o o o
316 PCB MAIN AS D901~902 DIODE DKN4002A-- 1N4002A AUTO 26MM o o o o
317 PCB MAIN AS D904~907 DIODE DRL202---- RL202 o o o o
318 PCB MAIN AS DZ601~602 DIODE ZENER DZTZ6R2A-- MTZ-6.2 52MM TAPPING o o o o
319 PCB MAIN AS IC201 IC 1LA1833N-- LA1833N o o o o
320 PCB MAIN AS IC202 IC 1LC72131D- LC72131D o o o o
321 PCB MAIN AS IC205 IC REGULATOR 1KA78L05AZ KA78L05AZ o o o o
322 PCB MAIN AS IC401 IC FUNCTION 1PT2314--- PT2314 o o o
323 PCB MAIN AS IC501 IC MOTOR DRIVE 1BA5939S-- BA5939S o o o o
324 PCB MAIN AS IC502 IC CHIP RF 1KB9223--- KB9223 RF+SSP+AF o o o o
325 PCB MAIN AS IC503 IC CHIP DSP 1KS9286B-- KS9286B DSP+DAC o o o o
326 PCB MAIN AS IC601 IC 1TA8189N-- TA8189N o o o o
327 PCB MAIN AS IC602 IC SWITCHING 1BA7755A-- BA7755A (HEAD SW) o o o o
328 PCB MAIN AS IC801 IC 1TDA7499-- TDA7499 o o
329 PCB MAIN AS IC801 IC 1TDA7265-- TDA7265 o o
330 PCB MAIN AS IC901 IC 1L4959---- L4959 o o o o
331 PCB MAIN AS J001 JACK ANT 9736321900 PAT645 o o
332 PCB MAIN AS J401 JACK RCA 9CD6313700 S-436P o o o o
333 PCB MAIN AS J801 JACK HEADPHONE 9766319501 HTJ-064-05B GOLD o o o o
334 PCB MAIN AS J802 JACK SPEAKER 9736320500 CJ-9007-040 o o o o
335 PCB MAIN AS JW201~202 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o o o
336 PCB MAIN AS JW203 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
337 PCB MAIN AS JW204~205 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o o o
338 PCB MAIN AS JW206 WIRE JUMPER W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO o o o o
339 PCB MAIN AS JW207 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o
340 PCB MAIN AS JW208 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o o o
341 PCB MAIN AS JW209 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
342 PCB MAIN AS JW210~211 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o o o
343 PCB MAIN AS JW213 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
344 PCB MAIN AS JW214~215 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO o o o o
345 PCB MAIN AS JW217 WIRE JUMPER W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO o
346 PCB MAIN AS JW402 WIRE JUMPER W581GY7595 AWG22 1/0.65 SN 7.5 AUTO o o o o
347 PCB MAIN AS JW403~404 WIRE JUMPER W581GY12J5 AWG22 1/0.65 SN 12.5 AUTO o o o o
348 PCB MAIN AS JW405 WIRE JUMPER W581GY7595 AWG22 1/0.65 SN 7.5 AUTO o o o o
349 PCB MAIN AS JW406~407 WIRE JUMPER W581GY7595 AWG22 1/0.65 SN 7.5 AUTO o o o
350 PCB MAIN AS JW501~504 WIRE JUMPER W581GY1005 AWG22 1/0.65 SN 10 AUTO o o o o
To Next Page
