Daewoo AMI-225M - Page 8

- 7 -
Mechanical Part List
NO Part Name Parts Code Q'ty Comment
1 PANEL FRONT 9CD0307900 1
2 WINDOW FLT 9CD1616400 1
3 DOOR CASS A 9CD18111A0 1
4 DOOR CASS B 9CD18111B0 1
5 WINDOW DOOR A 9CD16163A0 1
6 WINDOW DOOR B 9CD16163B0 1
7 KNOB VOLUME 9CD1339800 1
8 SPRING DOOR EJECT 9CD3004500 2
9 SPRING C HOLDER 9713008900 4
10 CUSHION FOOT 9CD4207700 2
11 DAMPER ASSY
9CD2603000
9CD2603100
1
12 BRAKET SIDE 9CD2412900 2
13 KNOB CONTROL 9CD1339500 1
14 KNOB CD 9CD1339700 1
15 KNOB POWER 9CD1339600 1
16 SHAFT VR 9CD3601900 1
17 SHAFT WASHER 9CD3602000 2
18 SPRING TUNING 9CD3007000 1
19
CASS DECK MECHANISM
9CD6007900 1
OPTION
20 KNOB DECK A 9CD13329R1 1
21 KNOB DECK B 9CD13330R1 1
22 DOOR CD 9CD1811200 1
23 CD DECK MECHSNISM 9CD6006900 1
24 HEAT SINK 05 9CD4405100 1
24-1 HEAT SINK 1 9CD4404500 1 OPTION
25 CHASSIS BOTTOM 9CD0608000 1
26 COVER SIDE L 9CD04115L0 1
27 COVER SIDE R 9CD04115R0 1
28 COVER BACK 9CD0409801 1
29 COVER TOP 9CD0411400 1
30 PLATE EON 9CD0910100 1
31 COVER ANT 9CD0410400 1
OPTION
32 LABEL SPK (6¥Ø) 9CD9309400 1
S1 SCREW TAPPTITE 7173260811 11
S2 SCREW TAPPTITE 7173301011 17
S3 SCREW TAPPTITE 7173301212 18
S4 SCREW TAPPTITE 7173401011 4
S5 SCREW TAPPTITE 7173300811 5
S6 WASHER SCREW 9CD3102400 1
P1 PCB FRONT 9CD6579800 1
P2 PCB MAIN 9CD6580000 1
P3 PCB FUSE 9CD6579700 1
P4 PCB GUIDE 9CD6579801 1
ABS
MIPS
ABS
ABS
ABS
ACETAL
SUS D0.6 ACD-7600
AUTO STOP
ABS
ABS
Description
MIPS
ACRYL
MIPS
MIPS
ACRYL
ACETAL
ACRYL
PW-1
ABS
STS (T=0.2)
URETHAN FOAM RUBBER
DA-12A
MIPS
DCC-01B
AL (5W)
MIPS
AL (10W)
MIPS
MIPS
MIPS
PVC SHEET
ABS
PE FILM
TT2 BIN 3X12 BK
TT2 BIN 4X10 MFZN
TT2 BIN 2.6X8 MFZN
TT2 BIN 3X10 MFZN
34 x 75 x 1.6T
13 x 32 x 1.6T
330 x 197 x 1.6T
247 x 139 x 1.6T
TT2 BIN 3X8 MFZN
TT2 BIN 3X10+D14
