816
LS
816
LSR
816
L
816
R
134 IC MICOM 1M38199917 M38199917 1 1 - - IC705
135 IC PRE AMP 1TM97CT38P LTM97CT-38P 1 1 1 1 [IC704 IC705]
136 IC SWITCHING 1BA7755A-- BA7755A (HEAD SW) 1 1 1 1 IC602
137 JACK ANTEN NA 9736322200 T-646 1 1 1 1 J001
138 JA C K HEADPHON E 9766319501 HTJ-064-05B GOLD 1 1 1 1 J901
139 JACK RCA 9CD6313700 S-436P 2 2 1 1 J461 [J903]
140 JACK SPEAKER 9736320500 CJ-9007-040 1 1 1 1 J902
141 LED DLTL16KEE- LTL-16KEE(RED)PI3.1 4 4 4 4 LD703 LD706 LD709 LD712
142 LED DLTL16KGE- LTL-16KGE(GREEN)PI3.1 8 8 8 8
LD701 LD702 LD704 LD705 LD707
LD708 LD710 LD711
143 LED DLTL307EE- LTL-307EE(RED)PI5 1 2 - 1 [LD713] [LD716] LD717
144 LED DLTL307GE- LTL-307GE(GREEN)PI5 3 3 - - LD713 LD714 LD715
145 LED DLTL87HEE- LTL-87HEE(RED)PI3 2 2 2 2 LD510 LD512
146 LED DLTL87HGE- LTL-87HGE(GREEN)PI3 2 2 2 2 LD511 LD513
147 PIN WAFER 9736407700 52084-1310 13P BOTTOM 1 1 1 1 CW401
148 PIN WRAPPING 9713550400 1.0X2.5X15 6 6 6 6
TP501 TP502 TP503 TP504 TP901
TP902
149 R CARBON FILM RD-2Y229J- 1/2 2.2 OHM J 1 1 1 1 R550
150 R CARBON FILM RD-4Z100J- 1/4 10 OHM J 2 2 2 2 R588 R589
151 R CARBON FILM RD-4Z101J- 1/4 100 OHM J 2 2 2 2 R814 R819
152 R CARBON FILM RD-4Z103J- 1/4 10K OHM J 7 7 7 7
R812 R815 R824 R825 R826
R827 R853
153 R CARBON FILM RD-4Z124J- 1/4 120K OHM J 1 1 1 1 R813
154 R CARBON FILM RD-4Z222J- 1/4 2.2K OHM J 2 2 2 2 R811 R820
155 R CARBON FILM RD-4Z393J- 1/4 39K OHM J 1 1 1 1 R828
156 R CARBON FILM RD-4Z472J- 1/4 4.7K OHM J 4 4 4 4 R809 R810 R821 R822
157 R CARBON FILM RD-4Z475J- 1/4 4.7M OHM J 1 1 1 1 R2
158 R CARBON FILM RD-4Z561J- 1/4 560 OHM J 2 2 2 2 R805 R806
159 R CARBON FILM RD-4Z562J- 1/4 5.6K OHM J 2 2 2 2 R837 R838
160 R CARBON FILM RD-4Z563J- 1/4 56K OHM J 2 2 2 2 R807 R808
161 R CARBON FILM RD-4Z681J- 1/4 680 OHM J 4 4 4 4 R846 R847 R848 R849
162 R CARBON FILM RD-4Z683J- 1/4 68K OHM J 1 1 1 1 R823
163 R CARBON FILM RD-4Z689J- 1/4 6.8 OHM J 6 6 4 4 [R743 R748] R842 R843 R844 R845
164 R CARBON FILM RD-AZ100J- 1/6 10 OHM J 9 9 8 8
R004 R009 R206 R255 R545
[R720 R762 R851] R907 R935
165 R CARBON FILM RD-AZ101J- 1/6 100 OHM J 20 20 20 20
R008 R102 R227 R228 [R301
R310 R319 R351 R360 R369]
R482 R546 R635 R654 R663
166 R CARBON FILM RD-AZ102J- 1/6 1K OHM J 44 44 44 44
R208 R215 R216 R251 R256 R260
R261 R262 R263 [R323] R421 R422
R480 R481 R484 R485 R488 R489
R511 R521 R522 R563 R564 R580
R601 R602 R603 R604 R613 R614
R636 R647 R659 [R725 R726
167 R CARBON FILM RD-AZ103J- 1/6 10K OHM J 52 52 43 43
L208 R213 R214 R254 R257
R258 [R324 R441 R442 R443]
R487 R579 R619 R620 R624
R639 R640 R641 R642 R653
R701 R702 R704 R705 R707
168 R CARBON FILM RD-AZ104J- 1/6 100K OHM J 19 19 20 20
R109 R471 R472 R473 R474
R502 R510 R518 R519 R548
R549 R567 R568 R584 R585
R648 R671 [R762 R763 R764
169 R CARBON FILM RD-AZ105J- 1/6 1M OHM J 6 6 6 6
R505 R508 R559 R560 R622
R665
170 R CARBON FILM RD-AZ106J- 1/6 10M OHM J 1 1 1 1 [R717 R759]
171 R CARBON FILM RD-AZ109J- 1/6 1 OHM J 2 2 2 2 R901 R902
172 R CARBON FILM RD-AZ121J- 1/6 120 OHM J 1 1 1 1 R551
173 R CARBON FILM RD-AZ122J- 1/6 1.2K OHM J - 1 1 - [R724 R753]
174 R CARBON FILM RD-AZ123J- 1/6 12K OHM J 10 10 10 10
R259 R509 R523 R531 R532
R533 R538 R539 R557 R558
175 R CARBON FILM RD-AZ124J- 1/6 120K OHM J 1 1 1 1 R513
176 R CARBON FILM RD-AZ151J- 1/6 150 OHM J 5 5 5 5
[R302 R311 R320 R352 R361
R370] R627 R628
177 R CARBON FILM RD-AZ152J- 1/6 1.5K OHM J 3 3 3 3 [R719 R720 R721 R778 R779 R780]
178 R CARBON FILM RD-AZ153J- 1/6 15K OHM J 5 5 6 6 [R371] R463 R464 R515 R553 R554
179 R CARBON FILM RD-AZ154J- 1/6 150K OHM J 2 2 2 2 R503 R525
180 R CARBON FILM RD-AZ181J- 1/6 180 OHM J 2 2 2 3 R303 R312 [R353 R362 R780]
181 R CARBON FILM RD-AZ182J- 1/6 1.8K OHM J 3 3 3 3 R401 R402 [R733 R741]
182 R CARBON FILM RD-AZ183J- 1/6 18K OHM J 5 5 5 5 R201 R203 R526 R643 R644
183 R CARBON FILM RD-AZ184J- 1/6 180K OHM J 7 7 6 6
R504 R625 R626 R637 R638
R651 [R723]
184 R CARBON FILM RD-AZ220J- 1/6 22 OHM J 1 1 1 1 R534
185 R CARBON FILM RD-AZ221J- 1/6 220 OHM J 4 4 4 4 R435 R552 R903 R904
186 R CARBON FILM RD-AZ222J- 1/6 2.2K OHM J 12 12 11 11
R211 R212 R253 R264 R433
R434 R486 R581 [R729 R737
R740] R742 [R745 R747]
187 R CARBON FILM RD-AZ223J- 1/6 22K OHM J 8 9 8 9
R107 R423 R424 [ R444] R528
R530 R615 R616 [R724 R725 R753]
188 R CARBON FILM RD-AZ224J- 1/6 220K OHM J 3 3 4 4 R629 R630 [R726 R766 R770]
189 R CARBON FILM RD-AZ271J- 1/6 270 OHM J 6 6 6 6
[R304 R313 R354 R363 R749
R751 R753 R755 R769 R771
R773 R775
No Parts Name Parts Code Description
Q'ty
Location
To Next Page
