816
LS
816
LSR
816
L
816
R
190 R CARBON FILM RD-AZ272J- 1/6 2.7K OHM J 9 9 8 8
R222 R223 [R322] R431 R432
R475 R478 R617 R618
191 R CARBON FILM RD-AZ273J- 1/6 27K OHM J 6 6 6 6
R542 R555 R556 R833 R834
R839
192 R CARBON FILM RD-AZ331J- 1/6 330 OHM J 6 6 5 5
R007 [R305 R314 R321 R355
R364] R483 R670
193 R CARBON FILM RD-AZ332J- 1/6 3.3K OHM J 8 8 8 8
R005 R106 R221 R516 R541
R543 R835 R836
194 R CARBON FILM RD-AZ333J- 1/6 33K OHM J 4 4 4 4 R621 R655 R656 [R716 R759]
195 R CARBON FILM RD-AZ334J- 1/6 330K OHM J 5 5 5 5
R650 R673 [R718] R760 [R761
R763 R776 R779]
196 R CARBON FILM RD-AZ390J- 1/6 39 OHM J - 2 - 1 [R756 R765 R784]
197 R CARBON FILM RD-AZ391J- 1/6 390 OHM J 8 6 7 6
[R306 R315 R356 R365 R748
R750 R752 R754 R756 R765
R768 R770 R772 R774 R784
198 R CARBON FILM RD-AZ392J- 1/6 3.9K OHM J 5 5 6 6 [R373] R403 R404 R529 R633 R634
199 R CARBON FILM RD-AZ393J- 1/6 39K OHM J 5 5 6 6 R520 R537 R572 R586 R587 [R718]
200 R CARBON FILM RD-AZ470J- 1/6 47 OHM J 4 5 4 5 R003 R209 R252 [R275] R657
201 R CARBON FILM RD-AZ471J- 1/6 470 OHM J 2 2 2 2 [R307 R316 R357 R366]
202 R CARBON FILM RD-AZ472J- 1/6 4.7K OHM J 25 25 25 25
R101 R103 R104 R105 R207 R210
R547 R561 R562 R565 R566 R573
R574 R575 R576 R577 R578 R582
R583 R645 R646 R662 R669 [R722
R752 R787 R788]
203 R CARBON FILM RD-AZ473J- 1/6 47K OHM J 5 5 6 7
R512 R658 [R745 R746 R750
R751 R757 R765 R781 R782]
204 R CARBON FILM RD-AZ474J- 1/6 470K OHM J 5 5 5 5 R217 R218 R501 R540 R661
205 R CARBON FILM RD-AZ479J- 1/6 4.7 OHM J 1 1 1 1 R652
206 R CARBON FILM RD-AZ561J- 1/6 560 OHM J 6 6 6 6
[R308 R317 R358 R367] R569
R570 R571 R668
207 R CARBON FILM RD-AZ562J- 1/6 5.6K OHM J 5 5 5 5 R476 R477 R527 R611 R612
208 R CARBON FILM RD-AZ563J- 1/6 56K OHM J 4 4 4 4 R514 R517 R803 R804
209 R CARBON FILM RD-AZ681J- 1/6 680 OHM J 5 6 1 1 R006 [R766 R767 R781 R782 R783]
210 R CARBON FILM RD-AZ682J- 1/6 6.8K OHM J 5 5 5 5 R219 R609 R610 R631 R632
211 R CARBON FILM RD-AZ683J- 1/6 68K OHM J 7 7 6 6
R607 R608 R623 R649 [R707
R708 R709 R717 R784]
212 R CARBON FILM RD-AZ689J- 1/6 6.8 OHM J - - 2 2 R739 R744
213 R CARBON FILM RD-AZ820J- 1/6 82 OHM J 5 5 3 3 [R445 R446] R506 R605 R606
214 R CARBON FILM RD-AZ821J- 1/6 820 OHM J 4 4 4 4 [R309 R318 R359 R368] R831 R832
215 R CARBON FILM RD-AZ822J- 1/6 8.2K OHM J 4 4 4 4 R461 R462 R507 R524
216 R CARBON FILM RD-AZ823J- 1/6 82K OHM J 2 4 2 4 [R276 R277] R535 R536
217 R CEME NT RX02L228J- 2W 0.22 OHM J 2 2 2 2 R829 R830
218 R FUSIBLE RF01F4780J 0.47OHM 1W 2 2 2 2 RF901 RF902
219 R SEMI FIXED RV1417222- 1/10 2.2K OHM B V6EK-PV1S 1 1 1 1 RV601
220 R SEMI FIXED RV6417223- VM6CK-PV(1S) B 22K OHM 3 3 3 3 RV201 RV501 RV502
221 RESONAT OR 5PCSA8MTZ- CSA8MTZ, 8MHZ 1 1 1 1 XC701
222 RE SONATOR CERA 5PCSA16R93 CSA16.93MXZ04 1 1 1 1 XC501
223 SW ENCOR DER 5SH162401- EC16B24204 24P W/DETENT 1 1 1 1 [VR701 VR702]
224 SW RELAY 5SC0101362 HR-RC112T2 12V 2A 1 1 - - RY801
225 SW RELAY 5SC0201103 HR-CR323 2C-1P DC12V 1 1 1 1 RY901
226 SW TACT 5S50101001 KPT-1105A 1C-1P 25 25 25 25
SW701 SW702 SW703 SW704 SW705
SW706 SW707 SW708 SW709 SW710
SW711 SW712 SW713 SW714 SW715
SW716 SW717 SW718 SW719 SW720
SW721 SW722 SW723 SW724 SW725
227 TR TKRA107M-- KRA107M (KSR2006) 1 1 1 1 Q003
228 TR TKRA111M-- KRA111-M TAPPING(KSR2010) 5 5 5 5 Q711 Q712 Q713 Q714 Q715
229 TR TKRC107M-- KRC107-M TAPPING(KSR1006) 4 4 4 4 Q701 [Q706] Q708 [Q709] Q710
230 TR TKRC111M-- KRC111M (KSR1010) 2 2 2 2 Q702 Q703
231 TR TKSA928AY- KSA928A-Y 2 2 2 2 Q501 Q502
232 TR TKSC2331Y- KSC2331Y 1 1 1 1 Q503
233 TR TKSR1003-- KSR1003 1 1 1 1 Q504
234 TR TZRA107M-- KRA107M (KSR2006) 2 2 2 2 Q613 Q614
235 TR TZRA111M-- KRA111M 2 2 2 2 Q610 Q611
236 TR TZRC107M-- KRC107M(AUTO) 2 2 2 2 Q618 Q716
237 TR TZRC111M-- K RC111M 3 3 3 3 Q612 Q616 Q619
238 TR TZTA1266Y- KTA1266Y- (AUTO)(1015Y) 4 4 4 4 Q603 Q604 Q617 Q803
239 TR TZTA1273-- KTA1273 1 1 1 1 Q901
240 TR TZTA1273Y- KTA1273Y(966Y) 4 4 4 4 Q615 Q705 [Q706] Q707 [Q709]
241 TR TZTC3194Y- KTC3194Y 1 1 1 1 Q001
242 TR TZTC3198Y- KTC3198Y-(1815Y) (AUTO) 16 16 15 15
Q201 Q202 Q471 Q472 Q505 Q606
Q607 Q608 Q609 Q704 Q801 Q802
Q804 Q805 [Q806] Q902
243 TR TZTC3205Y- KTC3205Y (2236Y) 1 1 1 1 Q605
244 TRANS POWER 5TP8074763 EI=74X62 230V 50HZ 1 1 1 1 PT901
245 TUNER PACK 9737612700 FTA3-503V 1 1 1 1 TU001
246 VFD DBJ638GK-- BJ638GK 1 1 - - FD701
247 VFD DSVA09 M M10 SV A09MM10 - - 1 1 FD701
248 WIRE JUMPER W581GY5095 AWG22 1/0.65 SN 5 AUTO 4 4 4 4 L801 L802 L841 L842
249 WIRE JUMPER W581GY6095 AWG22 1/0.65 SN 6 AUTO 2 3 2 3 CC908 [L270] R002
250 WIRE LEAD 9738834300 #26 1P 200MM 1 1 1 1 W601
251 X-TAL 5XA4R332M- 4.332M 1 1 - 1 XC270
252 X-TAL 5XA7R20000 7.2M 1 1 1 1 XC251
No Parts Name Parts Code Description
Q'ty
Location
