V
ehicle
Systems
Disassembly
&
Assembly
3.
Remove
bearing (3)
with wrench
(C).
4.
Remove rod
(4) from
the cylinder
body
.
5.
Remove split
rings (5)
from the
cylinder rod.
6.
Remove
O-ring seal
(6) and
back-up
ring (7)
from
the
bearing.
7.
Remove
wiper seal
(8) and
seal
(9) from
the
bearing.
27
ICD407P
IDCD408P
IDCD410P
IDCD41
1P
IDCD409P
C
4
5
5
6
7
8
9
27
29
